2/4×counter
The modular system
4.21
L
4.21−5
EDSPM−TXXX−9.0−11/2009
Type
2/4×counter
Voltage supply
DC 5 V / 80 mA (via backplane bus)
Connectable cable cross−section
£ 2.5 mm
2
(
³ AWG 14)
Counters
Number
2 × 32−bit counter or 4 × 16−bit counter
Operating modes
38 modes
Counting frequency
1 MHz
Inputs / outputs
External voltage supply
DC 24 V (DC 18 ... 28.8 V)
Input signal level
LOW: DC −30 ... +5 V
HIGH: DC +13 ... +36 V
Max. output current per output
0.5A
Communication
Input data
10 bytes
Output data
10 bytes
Parameter data
2 bytes
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight
100 g
Order number
EPM−T410
Technical data
