The modular system, 4×analog input – Lenze EPM−T9XX Modular system User Manual
Page 72

4×analog input
The modular system
4.14
L
4.14−4
EDSPM−TXXX−9.0−11/2009
Type
4×analog input
Voltage supply
DC 5 V / 280 mA (via backplane bus)
Connectable cable cross−section
£ 2.5 mm
2
(
³ AWG 14)
Analog inputs
Number
4
Input area
Voltage
−10 ... +10 V
−4 ... +4 V
−400 ... +400 mV
0 ... +50 mV
Information on tolerances
can be found in the chapter
"Parameter setting"
Current
−20 ... +20 mA
+4 ... +20 mA
Resistance
60
W, 600 W, 3 kW,6 kW
Resistor, temperature−dependent
PT100, PT1000, Ni100,
NI1000
Thermal element
J, K, N, R, S, T
Input resistance
Voltage range
2 M
W
Current range
50
W
Delay times
Conversion time/resolution
Conversion rate
[Hz]
3.7
7.5
15
30
60
123
168
202
Processing time per channel
[ms]
290
150
84
54
36
28
26
26
Resolution
[bit]
16
16
16
16
15
14
12
10
Electrical isolation from backplane bus
Yes, via optocouplers
Communication
Input data
8 bytes (2 bytes per analog input)
Parameter data
10 bytes
Diagnostic data
4 bytes
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight
100 g
Order number
EPM−T310
Technical data
