Lenze EPM−T9XX Modular system - Manual (Page 434)

Parameterising analog modules
Signal functions of 4xanalog input /output
13
Parameter setting via PROFIBUS−DP
13.1
13.1.10
L
13.1−22 EDSPM−TXXX−9.0−11/2009
Paramete
r bytes
4/5 Tolerance 2) Format 1) Signal range Signal function
06
h
Current signal
output 0 ... 20
mA 0.00
0 {0.01 mA}
{1
dec
}
+20.00
+16384
S5
Two’s
complement
±0.6 %
Min. Limit
values
Max.
0.00
0 +25.00 mA
+20480
dec
0Bh Current signal
output ±20 mA −20.00
−27648 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.3 %
Min. Limit
values
Max.
−23.52 mA
−32512
dec
+23.52 mA
+32511
dec
0C
h
Current signal
output 4 ... 20
mA +4.00
0 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.8 %
Min. Limit
values
Max.
0.00
−6912
dec
+22.81 mA
+32511
dec
0E
h
Current signal
output 0 ... 20
mA 0.00
0 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.6 %
Min. Limit
values
Max.
0.00
0 +23.52 mA
+32511
dec
FF
h
Analog output is switched off
1) Format of the output data ( ¶ 13.1−6).
2) Tolerance of the output range at an ambient temperature of 25 °C.
