4×analog input ±20mA
The modular system
4.16
L
4.16−3
EDSPM−TXXX−9.0−11/2009
Type
4×analog input ±20mA
Voltage supply
DC 5 V / 120 mA (via backplane bus)
Connectable cable cross−section
£ 2.5 mm
2
(
³ AWG 14)
Analog inputs
Number
4
Input range
− 20 ... + 20 mA
Tolerance
± 0.3 %
Input resistance
60
W
Max. input current
40 mA
Delay times
Conversion time/resolution
Processing time per channel
2 ms
Resolution
12 Bit
Electrical isolation from backplane bus
Yes, via optocouplers
Communication
Input data
8 bytes (2 bytes per analog input)
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight
80 g
Order number
EPM−T312
Technical data
