Lenze EPM−T9XX Modular system - Manual (Page 317)

Parameterising analog modules
Signal functions of 4xanalog input /output
12
Parameter setting via system bus (CAN) / CANopen
12.3
12.3.11
L
12.3−19 EDSPM−TXXX−9.0−11/2009
Paramete
r bytes
2/3 Tolerance 2) Format 1) Signal range Signal function
7D
h
Voltage
measurement 0 ... 10 V 0.00
0 {0.01V}
{1
dec
}
+10.00
+27648
S7
Two’s
complement
±0.4 %
Min. Limit
values
Max.
0.00
0 +11.76 V
+32511
dec
3A
h
Current
measurement ±20 mA −20.00
−16384 {0.01 mA}
{1
dec
}
+20.00
+16384
S5
Two’s
complement
±0.3 %
Min. Limit
values
Max.
−25.00 mA
−20480
dec
+25.00 mA
+20480
dec
76
h
Current
measurement 0 ... 20
mA 0.00
0 {0.01 mA}
{1
dec
}
+20.00
+16384
S5
Two’s
complement
±0.6 %
Min. Limit
values
Max.
0.00
0 +25.00 mA
+20480
dec
2C
h
Current
measurement ±20 mA −20.00
−27648 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.3 %
Min. Limit
values
Max.
−23.51 mA
−32512
dec
+23.51 mA
+32511
dec
2D
h
Current
measurement 4 ... 20
mA +4.00
0 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.8 %
Min. Limit
values
Max.
+1.18 mA
−4864
dec
+22.81 mA
+32511
dec
7E
h
Current
measurement 0 ... 20
mA 0.00
0 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.6 %
Min. Limit
values
Max.
0.00
0 +23.52 mA
+32511
dec
FF
h
Analog input deactivated
1) Format of the input data ( ¶ 12.3−7).
2) Tolerance of the input range at an ambient temperature of 25 °C. Sensor inaccuracies were not considered.
Lenze setting of the signal function in parameter bytes 2 and 3: 3B
h
