Index table
Appendix
15.1
L
15.1−1
EDSPM−TXXX−9.0−11/2009
15.1
Index table
l
The indices are numbered in ascending order for reference purposes.
l
How to read the index table:
Column
Abbreviation
Meaning
Index
Ixxxx
h
Index Ixxxx
h
1
Subindex 1 of Ixxxx
h
2
Subindex 2 of Ixxxx
h
Ixxxx
h
¿
After entry, the index parameter value is stored in the EEPROM
Ixxxx
h
*
Index parameter value is stored in the EEPROM with I2003
h
= 1
Name
Index name
Lenze
Lenze setting, setting on delivery
Selection
1
{%}
99
min. value
{unit}
max. value
Important
–
Brief, important explanations
^ Page x
Reference to detailed explanations
Index
Name
Possible settings
Important
Lenze
Selection
I1000
h
Device type
Display only
Type
I1001
h
Error register
Display only
^ 8.10−2
Bit 0
Generic
An unspecified error has occurred
(flag set on each error message)
Bit 1
Reserved
Bit 2
Reserved
Bit 3
Reserved
Bit 4
Comm.
Communication error (Overrun CAN)
Bit 5
Reserved
Bit 6
Reserved
Bit 7
ManSpec.
Manufacturer−specific error
Shown in detail in I1003
h
I1003
h
Display only
History buffer
1 Actual errors
I1004
h
Number of
supported PDOs
Display only
1 Number of
synchronous PDOs
supported
2 Number of
synchronus PDOs
supported
I1005
h
*
Sync COB−ID
128
128
{1}
2047
I1006
h
*
Sync interval (
ms)
0
0
{1
ms}
4294967295
·
I/O system IP20 acts as sync consumer:
– Set bit 30 = 0 under I1005
h
– After the time set under I1006
h
,
I/O system IP20 switches to the
communication status set under
I1029
h
– A reset will be carried out with the
next sync telegram
– With I1006
h
= 0, the monitoring is
deactivated
·
I/O system IP20 acts as sync producer:
– Set bit 30 = 1 under I1005
h
(Lenze
setting)
– I/O system IP20 transmits the sync
telegram after the time set under
I1006
h
