4×analog output
The modular system
4.17
L
4.17−3
EDSPM−TXXX−9.0−11/2009
Type
4×analog output
Voltage supply
DC 5 V / 30 mA (via backplane bus)
External voltage supply
DC 24 V / 200 mA (DC 19.2 ... 28.8 V)
Connectable cable cross−section
£ 2.5 mm
2
(
³ AWG 14)
Analog outputs
Number
4 outputs
Analog−to−digital converter
12 bits
Output ranges
Voltage
−10 ... +10 V
+1 ... +5 V
0 ... +10 V
Information on tolerances can be
found in the chapter "Parameter
setting"
Current
−20 ... +20 mA
+4 ... +20 mA
0 ... +20 mA
Actuator − input resistance
Voltage range
min. 1 k
W (output current max. 10 mA)
Current range
min. 500
W (output current max. 20 mA)
Delay time
10 ms
Electrical isolation from backplane bus
Yes, via optocouplers
Communication
Output data
8 bytes (2 bytes per analog output)
Parameter data
6 bytes
Diagnostic data
4 bytes
Dimensions
Width
25.4 mm
Height
76.0 mm
Depth
76.0 mm
Weight
100 g
Order number
EPM−T320
Technical data
