Parameterising analog modules
Signal functions of 4xanalog input /output
12
Parameter setting via system bus (CAN) / CANopen
12.3
12.3.11
L
12.3−18 EDSPM−TXXX−9.0−11/2009
12.3.11 Signal functions of 4xanalog input /output
)
Note!
l Short−circuit unused inputs (connect positive and negative
terminals) or deactivate them by assigning the function number
FF
h
.
l In the event of an overflow or underflow, wrong values are
output. Strong signal jumps with sign reversal may occur.
I/O system IP20 multiplies measured values with decimal positions and without
normalisation by a factor and transfers them as integers to the bus. To output the
decimal positions, divide the measured values by the same factor.
Example:
Measuring task: Temperature measurement with signal function 01
h
. Measured value = 80.5 °C.
1. I/O system IP20 converts the measured value into an integer:
80.5 [°C] × 10 = 805
2. Reconvert the measured value to output it with decimal positions:
805 [°C]
10
+ 80.5 °C
Paramete
r bytes
2/3 Signal function Signal range Format 1) Tolerance 2)
00
h
16 Parameter data in module are not overwritten
3Bh Voltage
measurement ±10 V −10.00
−16384 {0.01V}
{1
dec
}
+10.00
+16384
S5
Two’s
complement
±0.2 %
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
+20480
dec
75
h
Voltage
measurement 0 ... 10 V 0.00
0 {0.01V}
{1
dec
}
+10.00
+16384
S5
Two’s
complement
±0.4 %
Min. Limit
values
Max.
0.00
0 +12.50 V
+20480
dec
28
h
Voltage
measurement ±10 V −10.00
−27648 {0.01V}
{1
dec
}
+10.00
+27648
S7
Two’s
complement
±0.2 %
Min. Limit
values
Max.
−11.76 V
−32512
dec
+11.76 V
+32511
dec
7A
h
Voltage
measurement 1 ... 5 V +1.00
0 {0.01V}
{1
dec
}
+5.00
+27648
S7
Two’s
complement
±0.6 %
Min. Limit
values
Max.
0.00
−6912
dec
+5.704 V
+32511
dec
Input functions
