Parameterising analog modules
Signal functions of 4xanalog input /output
13
Parameter setting via PROFIBUS−DP
13.1
13.1.10
L
13.1−20 EDSPM−TXXX−9.0−11/2009
Paramete
r bytes
2/3 Tolerance 2) Format 1) Signal range Signal function
7E
h
Current
measurement 0 ... 20
mA 0.00
0 {0.01 mA}
{1
dec
}
+20.00
+27648
S7
Two’s
complement
±0.6 %
Min. Limit
values
Max.
0.00
0 +23.52 mA
+32511
dec
FF
h
Analog input deactivated
1) Format of the input data ( ¶ 13.1−6).
2) Tolerance of the input range at an ambient temperature of 25 °C. Sensor inaccuracies were not considered.
