Lenze EPM−T9XX Modular system - Manual (Page 308)

Parameterising analog modules
Signal functions of 4xanalog input
12
Parameter setting via system bus (CAN) / CANopen
12.3
12.3.5
L
12.3−10 EDSPM−TXXX−9.0−11/2009
Paramete
r bytes
2/3/4/5 Tolerance 2) Format 1) Signal range Signal function
3A
h
Current
measurement ±20 mA −20.00
−16384 {0.01 mA}
{1
dec
}
+20.00
16384
S5
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−23.70 mA
−19456
dec
+23.70 mA
+19456
dec
3Bh Voltage
measurement ±10 V −10.00
−16384 {0.01V}
{1
dec
}
+10.00
16384
S5
Two’s
complement
±0.2 % of the
final value
Min. Limit
values
Max.
−12.50 V
−20480
dec
+12.50 V
20480
dec
3D
h
Resistance
measurement with
four−wire
connection 60 W 0.00
0 {0.01 W}
{1
dec
}
+60.00
6000
dec
S7
±0.1 % of the
final value
3E
h
600 W 0.00
0 {0.01 W}
{1
dec
}
+600.00
6000
dec
±0.05 % of
the final value
3F
h
3000 W 0.00
0 {0.01 W}
{1
dec
}
+3000.00
30000
dec
±0.05 % of
the final value
57
h
Voltage
measurement 0 ... 50
mV 0.00
0 {0.01 mV}
{1
dec
}
+50.00
5000
S7
Two’s
complement
±0.1 % of the
final value
Min. Limit
values
Max.
0.00
0 +59.25 V
5925
dec
58
h
Voltage
measurement ±10 V −10.00
−10000 {0.01V}
{1
dec
}
+10.00
10000
S7
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−11.85 V
−11850
dec
+11.85 V
11850
dec
59
h
Voltage
measurement ±4 V −4.00
−4000 {0.01V}
{1
dec
}
+4.00
4000
S7
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−4.74 V
−4740
dec
+4.74 V
4740
dec
5A
h
Voltage
measurement ±400 mV −400
−4000 {1 mV}
{1
dec
}
+400
4000
S7
Two’s
complement
±0.1 % of the
final value
Min. Limit
values
Max.
−474 mV
−4740
dec
+474 mV
4740
dec
5C
h
Current
measurement ±20 mA −20.00
−20000 {0.01 mA}
{1
dec
}
+20.00
20000
S7
Two’s
complement
±0.05 % of
the final value
Min. Limit
values
Max.
−23.70 mA
−23700
dec
+23.70 mA
+23700
dec
