} Settings
Axis type
Type DMES...
Type DNCE...
Rotation drive
User config
5. Commissioning
5-8
Festo P.BE-MTR-DCI-PB-EN en 1209a
5.2.1 Selecting the axis type
1. Select your axis type:
– Festo positioning axis [Type DMES-...]
– Festo electrical drive [Type DNCE-...]
– Any axis of rotation [Rotation drive]
– Any linear axis [User config]
2. Set axis-specific parameters as prompted using the arrow
buttons, e.g. feed constant, system of measurement,
or counting direction.
Axis type Parameters
Type DMES A DMES size can be selected, according to the size of the MTR-DCI. The feed
constant is already configured.
Type DNCE – FeedCon: feed constant in [mm/rev]
(see documentation for your DNCE).
– Count direction: active direction (direction of motor rotation), left or right
(see 1.5).
Rotation drive 1) Any rotary/semi-rotary drive:
– [Degrees] (360°/rev) or
– [Revolutions]
User config Any linear drive: Feed constant in [mm/rev] as per the documentation of your
linear axis.
1) If an external gear is used, the gear factor can be set with FCT.
Tab. 5/2: Assigning parameters to the axis
3. Save the settings with SAVE .
