4. The control panel (type MTR-DCI-...-H2)

4-6

Festo P.BE-MTR-DCI-PB-EN en 1209a

4.2

The menu system

4.2.1

Accessing the main menu

When the power supply is switched on, the MTR-DCI auto-
matically carries out an internal check. At first the display
briefly shows the Festo logo, then changes to the status dis-
play. The status display shows the following information:

–

The type designation of your MTR-DCI

–

The current position of the drive x

a

= ....

–

The current setting for device control
(HMI = Human Machine Interface)

–

The PROFIBUS address of the MTR-DCI (PB:...).

The main menu is accessed from the status display using the

button. The current button function will be displayed
in the lower lines of the LCD display.

Function

Button

<- ->

You can use the arrow keys on the control panel
to select a menu item from the list. The current
selection is marked with an arrow (

} Diagnos-

tic). Select the menu item

V in order to display

further menu items (HMI control...).

v

V

ESC

With

you can interrupt the current entry
and return in stages to the higher menu level or
status display.

Menu

OK

With you can confirm the current selection
or entry.

Enter

Tab. 4/2: Button function (menu selection)
