4. The control panel (type MTR-DCI-...-H2)

4-10

Festo P.BE-MTR-DCI-PB-EN en 1209a

[System paramet.]

Menu command for displaying the following system para-
meters and data:

[System param]

Description

V power

[V]

Supply voltage

I max

[A]

Maximum current

I act

[A]

Current current

Temp

[°C]

Operating temperature

Cycle

Number of positioning movements

Ref. switch

on/off

Signal at reference switch input

Mode

e.g. mm

System of measurement units

Hom.meth.

–

bl.pos

–

bl.neg

–

sw.pos

–

sw.neg

Fixed stop in positive direction
Fixed stop in negative direction
Reference switch in positive direction
Reference switch in negative direction

Gear

e.g. 6.75

Gear reduction ratio of the MTR-DCI
