Chapter 6
76 Avaya C360 Manager User Guide
VoIP Config
The VoIP config tab allows you to view information about a specific VoIP
engine’s configuration.
Figure 6-2. VoIP config Tab
You can configure the IP address to be used in the IP Static Address field.
In addition, it is possible to see how many VoIP channels are available on
this engine.
The information in the VoIP config tab is provided by the VoIP engine and
is refreshed periodically.
The following table lists the fields in the VoIP config tab and their
description.
Table 6-5. VoIP config Parameters
Field Description
Slot # The slot in which the VoIP media module
engine is located.
MAC address The MAC address of the VoIP engine.
FW Version The firmware version on the VoIP engine.
IP Static address The IP address assigned to the VoIP Engine
when not using the DHCP server.
IP current address The current IP address of the VoIP engine.
Total Voice Channels Total number of channels available for this VoIP
engine.
