Avaya C360 Manager User Guide 89
WAN Configuration
3. Click PPP . The PPP tab of the Channel Group dialog box appears.
Figure 7-5. Channel Group Dialog Box - PPP Tab
The following table provides a list of the fields in the PPP tab of the
Channel Group dialog box and their descriptions:
Table 7-3. Channel Group Dialog Box - PPP Parameters
Field Description
Peer Address The IP address of the PPP session’s peer device.
MTU (octets) The size (in octets) of the largest datagram
that can be sent via the PPP session.
Keepalive The time, in seconds, between keepalive
messages. A value of 0 means that keepalive
messages are not sent.
