Avaya C360 Manager User Guide 183
14 Trap Managers Configuration
This chapter provides the information and instructions for configuring
managers for the Avaya C360 Device. It includes the following topics:
• Trap Manager Overview - An overview of trap managers.
• Viewing the Stack Trap Managers Table - Instructions on
accessing the device’s Trap Managers Table, and a description of
the Trap Managers Table.
• Viewing the Media Gateway Trap Managers Table -
Instructions on accessing the Media Gateway Trap Managers
Table, and a description of the Media Gateway TrapMedia
Gateway Table.
• Viewing the WAN Trap Managers Table - Instructions on
accessing the WAN Trap Managers Table, and a description of the
WAN Trap Managers Table.
• Editing the Trap Managers Table - Instructions on how to edit
the Trap Managers Table.
Trap Manager Overview
In the event of a fault or an unusual occurrence, the Avaya C360 can
send traps to one or more Network Management Stations (NMS). To
enable this feature, you must configure the Avaya C360 with a list of the
managers’ workstations. Traps are then sent to the stations listed in the
Managers table.
* Note: Up to ten managers can be assigned per device. However, it is
recommended to keep the list limited to actual and relevant
managers so as not to place undue stress on the network.
Using the Trap Managers Table, you can also configure which traps are
sent to specific managers. The columns to the right of the managers’ IP
addresses represent specific traps. Checking the checkbox in a trap
column enables the manager to receive the checked trap. Managers only
receive the traps which are checked.
