Chapter 15
196 Avaya C360 Manager User Guide
Viewing the Switch Connected Addresses
Window
The Switch Connected Addresses window provides a list of MAC
addresses along with the ports to which they are attached. To view the list
of connected stations:
Click .
Or
Select View > Switch Connected Addresses . The Switch Connected
Addresses window opens.
Figure 15-1. Switch Connected Addresses Window
All the connections to the Avaya C360 are listed with their respective
ports in the Switch Connected Addresses window. The rows of the Switch
Connected Addresses window comprise the following information:
• Mac Address - The MAC addresses of the stations connected to
the switch.
• Port - The number of the module and port in the switch.
To refresh the information in the Switch Connected Addresses window,
click
Refresh .
