Chapter 12
176 Avaya C360 Manager User Guide
Destination Port Selection Screen
The Destination Port Selection screen of the Port Mirroring Wizard helps
you select a destination port or LAG for the Port Mirroring pair. Ports and
LAGs which can be selected as destinations appear white in the Chassis
View.
Figure 12-4. Port Mirroring Wizard - Destination Port Selection Screen
To select a destination for the Port Mirroring pair, select a port or LAG in
the Chassis View. The selected port or LAG appears cyan in the Chassis
View and Tree View and is listed in the
Destination Port field in the wizard.
When you have finished selecting the destination for the Port Mirroring
pair, click
Next . The Port Mirroring Wizard continues with the Frames
Direction Selection Screen .
