Chapter 9
140 Avaya C360 Manager User Guide
Port Configuration Area
The Port Configuration Area enables you to configure a port’s VLAN
configuration. To view the Port Configuration Area, click
Port
Configuration . The Port Configuration Area appears.
Figure 9-3. Port Configuration Area
The following table provides a list of the configuration parameters in the
Port Configuration Area and their description.
Table 9-2. Port Configuration Area Parameters
Field Description
PVID The Port VLAN ID (PVID) of the port. This is the
VLAN of which the port is a member. The PVID
pull-down list contains all VLANs known to the
network and VLANs on the device.
Tagging Mode The tagging mode of the port. The tagging mode
controls the tagging of packets that can be
forwarded by the port. The following tagging
modes are available:
• Clear - The packet is forwarded with no
VLAN tag.
• IEEE-802.1Q - The packet is forwarded
with a VLAN tag in conformance with the
IEEE-802.q standard.
