Chapter 7
114 Avaya C360 Manager User Guide
USP - Frame Relay Interface
For USPs configured with a frame relay interface, the USP dialog box
contains five tabs:
• Serial Port - Basic information abut the USP. For information on
the fields in the Serial Port tab of the USP - Frame Relay dialog
box, refer to
“Serial Port” on page 106 .
• Advanced - Information about the channels that comprise the
interface. For information on the fields in the Advanced tab of the
USP - Frame Relay dialog box, refer to
“Advanced” on page 108 .
• Frame Relay - Information about the frame relay configuration
on the USP.
• Sub-Interfaces - Information about the Channel Group’s Frame
Relay sub-interface.
• DLCIs - DLCI information for the Channel Group.
Frame Relay
The Frame Relay tab of the USP dialog box provides information about
the frame relay configuration of the USP.
To view the Frame Relay tab of the USP dialog box:
1. Click a USP symbol in the Chassis View or Tree View. The USP
dialog box opens with the Serial Port tab.
