Avaya C360 Manager User Guide 95
WAN Configuration
To delete a Frame Relay sub-interface:
1. Click the Frame Relay sub-interface you want to delete.
* Note: You can only delete Frame Relay sub-interfaces on which no
IP interfaces are defined.
2. Click Delete .
3. Click Apply . The sub-interface is deleted.
The following table provides a list of the fields in the Frame Relay
Sub-Interfaces tab of the Channel Group dialog box and their
descriptions:
Table 7-5. Channel Group Dialog Box -
Sub-Interfaces Parameters
Field Description
Name The name of the interface.
Description A user defined description of the sub-
interface.
Type The type of Frame Relay sub-interface.
Currently, only Point-to-Point interfaces are
supported.
Bandwidth The bandwidth of the sub-interface in bits per
second.
Administrative Status The administrative status of the interface.
Possible statuses include:
• Enable
• Disable
