Avaya C360 Manager User Guide 223
IP Route
IP Interfaces
IP interfaces represent the logical connections of the device to the IP nets/
subnets attached to it. Each IP interface corresponds to one net/subnet.
When you create a new IP interface, RIP and OSPF interfaces are
automatically created and assigned enable status. When you delete an IP
interface, the device deletes the associated RIP and OSPF interfaces.
To define and display the IP interfaces, select IP Route > IP Interfaces . The
IP Interfaces window opens.
Figure 20-2. IP Interfaces WIndow
The following parameters are displayed:
Table 20-2. IP Interface Table Parameters
Field Description
Interface Name
(not for X330WAN
router)
The name assigned to the selected IP interface.
IP Interface Name
(X330WAN router
only)
The name assigned to the selected IP interface.
IP Address The IP address assigned to the device on this
subnet.
