Chapter 11
162 Avaya C360 Manager User Guide
4. Update the device. For more information on updating the device,
refer to “Updating the Device” on page 169 .
Adding a Port Redundancy
To add a new Port Redundancy:
1. Click Wizard . The Port Redundancy Wizard starts. For more
information, refer to “Port Redundancy Wizard” on page 163 .
Or
1. Click Insert . A row is added to the Port Redundancy dialog box.
2. Enter a name for the Port Redundancy in the Name field.
3. Select a port or a LAG from the Tree View or the Chassis View and
drag it to the Primary Port field. The port number or LAG name
appears in the Primary Port field.
4. Select a port or a LAG from the Tree View or the Chassis View and
drag it to the Secondary Port field. The port number or LAG name
appears in the Secondary Port field.
5. To configure the port redundancy as an extra resilient port
redundancy, check the Intermodule checkbox.
* Note: Only one intermodule port redundancy can be configured on
a device.
6. Update the device. For more information on updating the device,
refer to “Updating the Device” on page 169 .
* Note: A port cannot participate in more than one redundancy
scheme.
