Chapter 20
246 Avaya C360 Manager User Guide
3. Click Start. The OSPF Link State Database displays entries starting
with the specified LSA Type.
To view all the entries in the OSPF Link State Database:
Click .
Or
Select View > Refresh . All entries appear in the table.
OSPF External Database
To display the OSPF External Database window, select IP Route > OSPF >
OSPF External Database . The OSPF External Database window opens.
Figure 20-16. OSPF External Database Window
The following parameters are displayed:
Table 20-13. OSPF External Database Window
Field Description
LSA Type The type and format of the link state
advertisement; for example, Router links and
Network links.
LSA ID Identifies the part of the routing domain that is
described by the advertisement. The LSA ID can
be either a router ID or an IP address.
