Avaya C360 Manager User Guide 147
VLANs
Drag-and-Drop
To configure the PVID of ports using drag-and-drop:
1. Select the ports you want to configure in the Tree View, Chassis
View, or VLAN Tree. For information on selecting ports, refer to
“Selecting Ports” on page 145 .
2. Drag the ports until they are over a VLAN icon in the VLAN Tree.
The ports are added to the desired VLAN.
* Note: When dragging ports from the VLAN Tree, only ports
represented by PVID symbols are added to the desired VLAN.
Dragged static binding icons are ignored and do not change
port PVIDs.
Updating the Device
Ports whose VLAN information has changed appear dimmed in the
VLANs table. To update the device with the changes, click
Apply .
For more information on the user interface, refer to “Using Dialog Boxes
and Tables” on page 16 .
