Avaya C360 Manager User Guide 245
IP Route
The following parameters are displayed:
The parameters in the OSPF Link State Database window are read-only.
You can limit the table entries displayed. To start the display of entries
from a specified interface and IP address:
1. Click .
Or
Select Action > Start Point . The Start Point dialog box opens.
Figure 20-15. OSPF Link State Database Start Point Dialog Box
2. Select an LSA Type from the LSA Type listbox.
Table 20-12. OSPF Link State Database Window
Field Description
LSA Type The type and format of the link state
advertisement; for example, Router links and
Network links.
LSA ID Identifies the part of the routing domain that is
described by the advertisement. The LSA ID can
be either a router ID or an IP address.
Router ID Identifies the originating router in the
autonomous system.
Sequence No. The sequence number of the link state
advertisement. Use this parameter to detect old
and duplicate link state advertisements. The
larger the sequence number, the more recent
the advertisement. Note that the sequence
number is usually negative.
LSA Age The age of the link state advertisement (in
seconds).
Checksum This parameter is a checksum of the complete
contents of the advertisement, not including the
Age value.
