Chapter 6
72 Avaya C360 Manager User Guide
VoIP Resources
The VoIP resources tab provides administration parameters common to all
VoIP engines, such as the number of engines, QoS parameters, RTCP
configuration, and RSVP configuration.
Figure 6-1. VoIP resources Tab
General
The upper section of this dialog box displays general information common
to all VoIP engines.
The following table lists the general fields in the VoIP resources tab of the
VoIP Engine dialog box and their description.
Table 6-1. VoIP resources - General Parameters
Field Description
VoIP Engine # The number of VoIP engines in the media
gateway.
RTP port Min The minimum range of UDP ports assigned by
the call controller for RTP traffic. The value
ranges between 1 - 65534.
