Avaya C360 Manager User Guide 243
IP Route
You can modify OSPF interfaces. For more information on editing tables,
refer to
“Editing Tables” on page 213 .
OSPF Area Parameters
To define and display OSPF Area Parameters, select IP Route > OSPF >
OSPF Area Parameters . The OSPF Area Parameters window opens.
Figure 20-13. OSPF Area Parameters Window
The following parameters are displayed:
Auth Key The password for this interface. This is only used if
the
Auth Type is set to Simple-password . The
password may contain up to 8 characters. It may
be configured here, but not viewed.
Table 20-10. OSPF Interfaces (Continued)
Field Description
Table 20-11. OSPF Area Parameters
Field Description
Area ID A unique number identifying the OSPF area to
which this router belongs. Area ID 0.0.0.0 is
used for the OSPF backbone.
Stub Area If checked, external link-state advertisements
are not imported into the area.
