Avaya C360 Manager User Guide 251
IP Route
State The state of the virtual router. Possible states
are:
• initialize - The virtual router is not
functional.
• backup - The virtual router is monitoring
the availability of the master router.
• master - The virtual router is forwarding
packets with IP addresses associated with
this virtual router.
Master IP Address The IP address of the physical router currently
acting as the Virtual Router’s Master Router.
Priority This object specifies the priority to be used for
the virtual router master election process.
Higher values imply higher priority.
A priority of '0', although not settable, is sent by
the master router to indicate that this router has
ceased to participate in VRRP and a backup
virtual router should transition to become a
new master.
A priority of 255 is used for the router that
owns the associated IP address(es).
Virtual Route Up
Time The time when the virtual router’s state
changed from initialized to
backup or master . The
time is expressed in ticks (1/60 of a second).
Advertise Interval The interval, in seconds, between VRRP
advertisement messages sent by the master
router.
MAC Address The virtual MAC address of the virtual router.
Primary IP Address The physical router’s IP address to be used if it is
elected to be Master Router. The Primary IP
Address must belong to the physical router and
be on the selected VLAN.
If this parameter is set to 0.0.0.0, the IP address
which is numerically lowest will be selected.
Preempt Mode If checked, the virtual router with the highest
priority will preempt active routers and become
the master router.
Table 20-16. VRRP Table Parameters (Continued)
Field Description
