Avaya C360 Manager User Guide 121
WAN Configuration
To modify the parameters of a DLCI:
1. Click the DLCI you want to modify. The configuration parameters
of the selected DLCI appear in the bottom of the dialog box.
2. Modify the parameters you want to change using the fields at the
bottom of the dialog box.
3. Click Apply . The DLCI parameters are modified.
To delete a DLCI:
1. Click the DLCI you want to delete.
2. Click Delete . A confirmation dialog box opens.
3. Click Yes .
4. Click Apply . The DLCI is deleted.
The following table provides a list of the fields in the DLCIs tab of the USP
dialog box and their descriptions:
Table 7-13. USP Dialog Box - DLCIs Parameters
Field Description
DLCI The DLCI for the circuit.
Type The method used to create the DLCI. Possible
methods include:
• Local - The DLCI was created manually.
• Unused - The DLCI was created using
the LMI interface.
Status The operational status of the DLCI. Possible
statuses include:
• Active - The DLCI is active.
• Inactive - The DLCI is inactive.
• Deleted - The DLCI has been deleted.
• Invalid - The DLCI is not valid.
Sub Interface The Sub-Frame-Relay interface associated
with the DLCI.
