Avaya C360 Manager User Guide 253
IP Route
CRTP
The CRTP folder provides access to the following window:
• CRTP Interfaces
CRTP Interfaces
The Avaya X330WAN router supports RTP compression, reducing the
overhead of transmitting voice packets over the E1/T1 line. You can
configure CRTP (Compressed RTP) parameters for each PPP interface on
the X330WAN router.
* Note: The CRTP Interfaces window is only available on an
X330WAN router.
To define and display CRTP Interfaces, select IP Route > CRTP >
CRTP Interfaces . The CRTP interfaces window appears.
Figure 20-20. CRTP Interfaces WIndow
The following parameters are displayed:
Table 20-17. CRTP Interface Table Parameters
Field Description
Layer 2 Interface
Name The name of the selected interface.
