Avaya C360 Manager User Guide 117
WAN Configuration
Sub-
Interfaces
The Sub-Interfaces tab of the USP dialog box provides information about
the configuration of Sub-Frame-Relay interfaces in the USP.
To view the Sub-Interfaces tab of the USP dialog box:
1. Click a USP symbol in the Chassis View or Tree View. The USP
dialog box opens with the Serial Port tab.
2. Click Sub-Interfaces . The Sub-Interfaces tab of the USP dialog box
appears.
Figure 7-19. USP Dialog Box - Sub-Interfaces Tab
The Sub-Interfaces tab of the USP dialog box provides a list of Frame
Relay sub-interfaces in the upper section of the dialog box. To view
configuration information for a specific Frame Relay sub-interface, click
the sub-interface in the list. Configuration information for the selected
Frame Relay sub-interface appears in the bottom of the dialog box.
You can create, modify, and delete Frame Relay sub-interfaces using the
Sub-Interfaces tab of the USP dialog box.
To create a new Frame Relay sub-interface:
1. Click New . A new row appears in the Sub-Frame-Relay Interfaces list.
Backup INterface The interface configured to back up this
interface.
Table 7-11. USP Dialog Box - Frame Relay Parameters (Continued)
Field Description
