Avaya C360 Manager User Guide 39
Device Configuration
For more information on the user interface, refer to “Using Dialog Boxes
and Tables” on page 16 .
Viewing Port Configuration
The Port Configuration dialog box contains tabs that provide you with
information specific to a selected port.
The General tab of the Port Configuration dialog box provides detailed
information about the port, such as the port name, type, functionality,
status, VLAN ID, mode of operation, and any faults occurring on the port.
The Advanced tab of the Port Configuration dialog box provides detailed
information about the port’s STP configuration and port classification.
The 802.1x tab of the Port Configuration dialog box provides detailed
information about the port’s 802.1x configuration. For more information
about 802.1x security, refer to
Chapter 16, Port Security .
The Power tab of the Port Configuration dialog box provides information
about the port’s PoE configuration. For more information about PoE, refer
to
Chapter 4, Power over Ethernet .
The LLDP tab of the Port Configuration dialog box provides configuration
information for the Link Layer Display Protocol on the port.
The Get/Set Toolbar provides an alternative, quick method to view and
change the port’s configuration. For more information on the Get/Set
Toolbar, refer to
“Get/Set Toolbar” on page 10 .
* Note: The configuration of ports that participate in a LAG cannot be
changed using the Port Configuration dialog box. Use the LAG
Configuration dialog box instead.
Port Classification The classification of a specific LAG. Port
Classification allows network managers to
specify each LAG level’s importance. The
possible states are:
• Regular - Normal users.
• Valuable - Servers or critical users.
For more information refer to Port Classification
in The Reference Guide.
Table 3-6. LAG Configuration Fields - Advanced Tab (Continued)
Field Description
