Chapter 20
228 Avaya C360 Manager User Guide
When adding Routing Table entries on an Avaya X330WAN router, you
can configure the next hop method in the Form View. Available next hop
methods include:
• Next Hop - Select the Next Hop option button, and enter the IP
address of the next hop.
• L2 Interface Name - Select the L2 Interface Name option button,
and select an interface from the pull-down listbox.
• Discard - Select the Discard option button.
You can limit the table entries displayed. To start the display of entries
from a specified interface and IP address:
1. Click .
Or
Select Action > Start Point . The Start Point dialog box opens.
Figure 20-4. Routing Table Start Point Dialog Box
2. Enter an IP address in the Destination field.
3. Click OK . The Routing Table displays entries starting with the
specified IP address.
To view all the entries in the Routing Table:
Click .
Or
Select View > Refresh . All entries appear in the table.
