Chapter 3
44 Avaya C360 Manager User Guide
For more information on the user interface, refer to “Using Dialog Boxes
and Tables” on page 16 .
Port Configuration - Advanced Tab
To view the Advanced tab of the Port Configuration dialog box for a
selected port:
1. Click the port symbol in the Chassis View.
Or
Click the port’s icon in the Tree View. The Port Configuration
dialog box opens to the General tab.
2. Click Advanced . The Advanced tab of the Port Configuration dialog
box appears.
Figure 3-8. Port Configuration Dialog Box - Advanced Tab
