Avaya C360 Manager User Guide 13
Device Manager
The following table provides a list of the possible port and LAG colors in
the Chassis View and their meaning.
GBIC Ports
Some Avaya C360 expansion modules contain GBIC (GigaBit Interface
Converter) ports that house removable transceiver modules. The Chassis
View reflects the management status of the ports. The following table
shows the possible appearances of these ports in the Chassis View and
provides the corresponding management status of the port.
GBIC ports that contain the following types of transceiver modules can be
configured:
• Supported transceiver modules
• No transceiver modules
• Unknown transceiver modules
Table 2-3. Chassis View Port/LAG Colors
Color Meaning
Green The port/LAG is enabled, and its status is Okay.
Yellow The port/LAG is enabled, and its status is Warning.
Red The port/LAG is enabled, and its status is Fatal.
Light Gray The port/LAG is disabled.
Dark Gray The port/LAG is not associated with the assignment.
White The port/LAG is logically available for assignment.
Dark Blue The port/LAG has been assigned the primary position in
an application.
Cyan The port/LAG has been assigned a secondary position in
an application.
Table 2-4. GBIC Port Status
GBIC Port Status
The GBIC port contains a supported transceiver
module.
There is no transceiver module present in the GBIC
port.
The transceiver module in the GBIC port is not
supported.
The transceiver module in the GBIC port is of an
unknown type.
