Avaya C360 Manager User Guide 151
Link Aggregation Groups
Creating LAGs
To create a new LAG, click Wizard . The LAG Wizard starts.
For more information, refer to “The LAG Wizard” on page 151 .
Editing LAGs
To edit an existing LAG:
1. Select a LAG by clicking on the row representing the LAG.
2. Click Wizard . The LAG Wizard starts.
When editing a LAG, the LAG Wizard’s dialog boxes display the current
LAG configuration parameters. To keep the values currently displayed in
one of the dialog boxes, click
Next . If you have changed some of the LAG’s
parameters, and you want to keep the rest of the LAG’s configuration,
click
Finish . The device is updated with the LAG’s new configuration.
For more information, refer to “The LAG Wizard” on page 151 .
The LAG Wizard
This section provides detailed information on each of the LAG Wizard’s
screens. To continue to the next screen, click
Next . To return to an earlier
screen, click Back . To exit the LAG Wizard without making any changes,
click Cancel .
The LAG Wizard consists of the following screens:
• Welcome Screen
• Base Port Selection Screen
• Member Port Selection Screen
• LAG Name Screen
• Confirmation Screen
The following sections describe each of the LAG Wizard screens.
