Chapter 7
98 Avaya C360 Manager User Guide
3. Click Apply . The DLCI parameters are modified.
To delete a DLCI:
1. Click the DLCI you want to delete.
2. Click Delete .
3. Click Apply . The DLCI is deleted.
The following table provides a list of the fields in the DLCIs tab of the
Channel Group dialog box and their descriptions:
To configure the priority of DLCI traffic, select the checkboxes for the
priorities to use on the DLCI.
If only one DLCI is configured for the Channel Group, all traffic uses the
DLCI.
Table 7-6. Channel Group Dialog Box - DLCIs Parameters
Field Description
DLCI The DLCI for the circuit.
Type The method used to create the DLCI. Possible
methods include:
• Local - The DLCI was created manually.
• Unused - The DLCI was created using
the LMI interface.
Status The operational status of the DLCI. Possible
statuses include:
• Active - The DLCI is active.
• Inactive - The DLCI is inactive.
• Deleted - The DLCI has been deleted.
• Invalid - The DLCI is not valid.
Sub Interface The Sub-Frame-Relay interface associated
with the DLCI.
Role Set The priority of traffic on the selected DLCI.
Possible priorities include:
• Primary
• High
• Medium
• Normal
• Low
