Chapter 14
186 Avaya C360 Manager User Guide
For information on adding and removing trap managers and editing their
trap reporting statuses, refer to
“Editing the Trap Managers Table” on
page 193 .
Stack Trap Managers Table - SNMPv3 Tab
To view the Stack Trap Managers Table SNMPv3 tab:
1. Verify that a G700 or X330WAN module is not selected.
2. Click .
Or
Select Configure > Trap Managers . The Stack Trap Managers Table
dialog box opens to the SNMPv1 Legacy tab.
3. Click SNMPv3. The Stack Trap Managers Table dialog box opens to
the SNMPv3 tab.
IP Access Control
Traps A trap that reports the arrival of a
packet which is assigned not to enter
the router.
Duplicate IP Traps A trap that reports that a user has
configured a device on the network
with an IP address that is already being
used by the router.
Table 14-1. Trap Types (Continued)
Icon Trap Description
