Avaya C360 Manager User Guide 187
Trap Managers Configuration
Figure 14-2. Stack Trap Managers Table - SNMPv3 Tab
The following table provides a list of the fields in the SNMPv3 tab of the
Stack Trap Manager Table dialog box and their descriptions.
Table 14-2. Stack Trap Manager Options - SNMPv3 Tab
Field Description
Manager IP IP address of the destination Trap Manager.
User Name User name to access the Trap Manager.
Notify Mode Security model used to send traps to Trap
Managers. Possible values are:
• SNMPv1
• SNMPv2
• SNMPv3-No Auth
• SNMPv3-Auth
• SNMPv3-Auth Priv
Inform Timeout The amount of time in seconds that the device
will attempt to contact the Trap Managers.
Possible values are 100-10,000.
