Avaya C360 Manager User Guide 75
VoIP Engine Configuration
RSVP
RSVP is a protocol that signals the router to reserve bandwidth.
If RSVP is enabled, the G700 Media Gateway tries to reserve a specific
amount of bandwidth per call session. If this fails, the Media Gateway
tries to reallocate the bandwidth during the call session.
The following table lists the RSVP fields and their description.
Table 6-4. VoIP resources - RSVP Parameters
Field Description
RSVP Enabled The Status of RSVP usage.
• Checked - The G700 Media Gateway will
try to reserve bandwidth per call. If it fails,
the G700 Media Gateway will try again
during the call.
• Unchecked - RSVP is not enabled.
Retry on failure The action the VoIP engine takes after an RSVP
request fails.
• Checked - The VoIP engine resends a
RSVP request if the first attempt failed.
• Unchecked - The VoIP Engine drops the
RSVP request, and the Retry Delay field is
ignored.
Retry Delay The interval the VoIP Engine waits after a failed
RSVP request before sending the new request.
The interval ranges between 0.5 - 60 seconds.
Service profile The type of service being provided.
