Avaya C360 Manager User Guide 247
IP Route
The parameters in the OSPF External Database window are read-only.
OSPF Neighbors
To display the OSPF Neighbors window, select IP Route > OSPF >
OSPF Neighbors . The OSPF Neighbors window opens.
Figure 20-17. OSPF Neighbors Window
Router ID Identifies the originating router in the
autonomous system.
Sequence No. The sequence number of the link state
advertisement. Use this parameter to detect old
and duplicate link state advertisements. The
larger the sequence number, the more recent
the advertisement. Note that the sequence
number is usually negative.
LSA Age The age of the link state advertisement (in
seconds).
Checksum This parameter is a checksum of the complete
contents of the advertisement, not including the
Age value.
Table 20-13. OSPF External Database Window (Continued)
Field Description
