Chapter 5
60
Avaya C360 Manager User Guide
G700 Configuration
This section describes how to view and set the various configuration
parameters relevant to the G700 Media Gateway. It includes the following
sections:
•
- View information specific to a
G700 Media Gateway module in the device.
•
Viewing Media Module Configuration
- View information
specific to a Media Module in the device.
Viewing Module Configuration
The Module Configuration dialog box provides you with information
about a selected module. To view the configuration of a module:
Click the module symbol in the Tree View.
Or
Click the module’s label in the Chassis View. The Module
Configuration dialog box opens.
The Module Configuration dialog box for G700 modules contains four
tabs:
•
•
•
•
* Note: For information about configuring Avaya C360 Modules other
than the G700 Media Gateway, refer to
Switch
Config
The Switch Config tab provides detailed information about the module,
such as the module’s position in the device, the module’s type,
description, number of ports, and any faults occurring on the module.
For information about the fields in the Switch tab, refer to
Module Configuration” on page 24
.
