Chapter 5
68 Avaya C360 Manager User Guide
The following table lists the fields in the Media Module Configuration
dialog box and their description.
Avaya Site Administration
Avaya Site Administration (ASA) is an administration tool for Avaya Call
Processing call control software. ASA is used to configure the current
MGC, G700 Media Gateway, or an individual voice port.
To launch ASA on an MGC, G700 Media Gateway, or voice port:
1. Click the component in the Tree View or Chassis View.
2. Click .
Or
Select Tools > Administer Station/Gateway . ASA opens with the
configuration form of the selected component.
Table 5-7. Media Module Configuration Parameters
Field Description
MM Identifier The Media Module’s identifier.
MM Type The type of Media Module. Possible values are:
• E1/T1
• ISDN BRI
• Analog
• Digital
• VoIP
• ICC
MM Description An optional description of the specific Media
Module.
Serial # The serial number of the Media Module.
HW Version The version of the Media Module’s hardware.
FW Version The firmware version of the Media Module.
Number of Ports The number of ports on the Media Module.
Operational Status The operational status of the Media Module.
