Chapter 20
236 Avaya C360 Manager User Guide
RIP Interfaces
To define and display RIP interfaces, select IP Route > RIP > RIP Interfaces .
The RIP Interfaces window opens.
Figure 20-10. RIP Interfaces Window
The following parameters are displayed:
Table 20-8. RIP Interface Parameters
Field Description
Interface Name The name assigned to the selected IP interface.
IP Address The IP address of the interface.
State The operational status of the RIP interface -
active or inactive.
Status The administrative status of the RIP interface. If
checked, the RIP interface status is enabled. If
unchecked, it is disabled.
