Avaya C360 Manager User Guide 189
Trap Managers Configuration
Viewing the Media Gateway Trap Managers
Table
To view the Trap Managers table for a G700 Media Gateway:
1. Select the G700 Media Gateway for which you want to view the
Trap Managers table.
* Note: Each G700 Media Gateway module has its own Trap
Managers table, which can be used to configure IP addresses
and trap managers for the specific module. Device wide trap
settings do not apply to traps from G700 Media Gateways in
the device.
2. Click .
Or
Select Configure > Trap Managers . The Media Gateway Trap
Managers table opens.
Figure 14-3. Media Gateway Trap Managers Table
The Media Gateway Trap Managers table is used to configure the IP
addresses of the trap managers and their trap reporting statuses for Media
Gateway traps. Traps include power, fan, faults, module insert/remove,
and voice related traps.
To enable RTP QoS traps on the Media Gateway module, check the Enable
RTP QoS traps checkbox. To disable frame relay traps on the Media Gateway
module, uncheck the Enable RTP QoS traps checkbox.
