Avaya C360 Manager User Guide 225
IP Route
You can create, modify, and delete IP interfaces. For more information on
editing tables, refer to
“Editing Tables” on page 213 .
* Note: The IP Address, IP NetMask, If Name, and Status must be
defined before creating an IP interface.
* Note: The list of VLANs allocated in the system is displayed in the
If Name field.
Routing Table
To display and update the Routing Table, select IP Route > Routing Table .
The Routing Table window opens.
Figure 20-3. Routing Table
ICMP Redirect
Status The state of ICMP message redirection on the
interface. Possible states are:
• enable - ICMP redirect messages are
enabled on this interface.
• disable - ICMP redirect messages are
disabled on this interface.
Table 20-2. IP Interface Table Parameters (Continued)
Field Description
