Avaya C360 Manager User Guide 109
WAN Configuration
2. Click the Advanced tab. The Advanced tab of the USP Configuration
dialog box appears.
Figure 7-16. USP Configuration Dialog Box - Advanced Tab
The following table lists the configuration fields in the Advanced tab of
the USP Configuration dialog box and their descriptions:
Table 7-9. USP Configuration - Advanced Parameters
Field Description
Clock Source The clock source for this interface. This value is
read-only. Possible values are:
• Internal
• External
• Loopback
Linecode The type of linecode. Possible values are:
• Nrz
• Nrzi
DCD The port’s Data Carrier Detect status. Possible
values are:
• Up - The port has successfully detected
Data Carrier. This process takes place
during initial line signalling.
• Down - The port has either not detected
Data Carrier or has completed the
detection process.
