Avaya C360 Manager User Guide
35
Device Configuration
For more information on the user interface, refer to
LAG Configuration - Advanced Tab
To view the Advanced tab of the LAG Configuration dialog box for a
selected LAG:
1. Click the LAG’s symbol in the Tree View.
Or
Click the LAG’s icon in the Chassis View. The LAG Configuration
dialog box opens to the General tab.
Operational Status
The warning level of the ports on the selected
LAG. Possible values are:
• OK
• Warning
• Fatal
Fault Messages
A list of fault messages.
Table 3-5. LAG Configuration Fields - General Tab (Continued)
Field
Description
