Chapter 20
226 Avaya C360 Manager User Guide
The following parameters are displayed:
Table 20-3. Routing Table Parameters
Field Description
Destination The destination network IP address of this
route. An IP address of 0.0.0.0 denotes a default
router.
Netmask The destination network mask of this route.
Next Hop The address of the next router of this route, via
which the destination of this route is reached.
VLAN Name
(not for X330WAN)
The logical name of the local interface through
which the next hop of this route is reached.
L2 Interface Name
(X330WAN router
only)
The logical name of the local interface through
which the next hop of this route is reached.
Protocol The protocol through which the route was
learned. The following protocols can be
specified:
• Static - The route was manually configured
to this device.
• Local - The route represents a directly
attached
net/subnet and corresponds to one of the
IP interfaces configured to this device.
• RIP - The entry was learned from the RIP
protocol.
• OSPF - The entry was learned from the
OSPF protocol.
Leak Route If checked, static entries are advertised by RIP
and OSPF. If unchecked, static entries are not
advertised.
Cost Number of hops to the destination network, or
the cost of the route for OSPF routes.
Permanent
(X330WAN router
only)
The permanence status of the route. Possible
statuses are:
• Checked - The route is not disabled when
a link on the route is down.
• Unchecked - The route is disabled when a
link on the route is down.
